Wing Installation
1. Before installing the wing, the main landing gear needs to be down for installing the front wing bolts.
a. Lower the throttle and throttle trim to the lowest setting. Power on the Transmitter and wait 5 seconds.
b. Connect the ESC and retract connector to the receiver and power on with battery.
c. Let the main landing gear down using the retract channel on your transmitter.
2. Install the wing
a. Remove the canopy hatch
b. Guide the Multi Connector wires through the hole located in the bottom of the fuselage as shown.
c. Align the wing with the fuselage and secure into position using screws PM3.0x 18mm and PM 3.0x 32mm.
6
fig5
fig6
