The transmitter outputs a total of 4 channels, which are allocated as follows:
1. CH1：Steering Wheel 2. CH2：Throttle Trigger
3. CH3：Three-position Switch 4. CH4：Reset Button
Note: By default the output of CH4 is 1000us, pressing the button will toggle between 1000 and 2000us
This function is used to adjust each channels direction of movement in relation to it’s input.
The ST.REV / TH.REV switches are the reverse buttons for CH1 and CH2. If the switch is up it indicates reverse, and
the down indicates normal.
The ST.TRIM is the trims for CH1 (steering),and can be multiplexed as trims of CH3 and CH4.
For multiplexing switching mode, refer to [5 Mode Switching].
TH.TRIMis the trims for CH2(throttle).
Adjustment range: -120us- + 120us, each step is 4us;
ST.TRIM + / TH.TRIM +: Increases adjustment step;
ST.TRIM- / TH.TRIM-: Decreases adjustment step.
LED Indicator:
When using the trim keys the G.LED will flash slowly on short presses and quickly on long presses.
When the trim adjustment value is at the netrual position, the G.LED will flash twice slowly.
When the trim adjustment value is at both ends (+ 120us / -120us), the trim adjustment is at its maximum and
as such G.LED will not flash(If the fine adjustment value has been adjusted to + 120us, then press ST.TRIM +
/ TH.TRIM + key is invalid and G.LED has no indications.)
该发射机共输出4个通道，分配如下:
1. CH1： 方向手轮 2. CH2：油门扳机
3. CH3：三档开关 4. CH4：复位按键
注意：CH4 按键开机默认输出 1000us，按压操作一下通道值翻转 - 次，数值在 1000us/2000us 之间互相切换。
按键ST.REV/TH.REV分别为CH1、CH2通道反向按键，开关上拨表示反向，下拨表示正常。
ST.TRIM 为 CH1 方向微调，可复用为 CH3、CH4 微调，复用切换方式见 [5 模式切换 ]；
TH.TRIM 为 CH2 油门微调。
调节范围：-120us-+120us，微调步进为 4us；
ST.TRIM+/TH.TRIM+：增大微调值；
ST.TRIM-/TH.TRIM-：减少微调值。
LED指示情况:
操作一次微调键 G.LED 闪烁一次，长按快闪
当微调值位于中点时 G.LED 慢闪 2 下
当微调值位于两端时（+120us/-120us），微调无效且 G.LED 无指示（如微调值已调至 +120us，此时按
ST.TRIM+/TH.TRIM+ 键无效且 G.LED 无指示）
Trims
微调
Channel Description
通道说明
Channel Reverse
通道反向（该功能用于调整舵机或马达的动作方向。）
System Functions
系统功能
10
