5
3.Twist the tail section to the left and secure it using the snap
lock system. The tail section is successfully secured when a
click is heard.
1.Pull back on the latch, releasing the canopy.
2.Remove the canopy, revealing the battery compartment.
3.Apply hook and loop tape to the battery.
4.Install a fully charged battery into the battery compartment, with
the battery cables facing aft.
Note: The center of gravity can be adjusted by moving the battery
forward or aft.Having the correct center of gravity is critical to
achieving proper flight characteristics.
Model assembly
Battery installation
