Horizontal and stabilizers installation
1. Connect the rudder servo connectors to the servo extensions in
the elevator .
2. Complete the tail assembly by attaching the vertical stabilizers
to the slots located on the horizontal stabilizer.
3.Secure the two vertical tail pieces (left and right) in place using
the 4 screws included.
4.Connect the elevator servo connectors and rudder servo
connectors to the servo extensions in the fuselage.
5
Model assembly
HKM3.0*16
