4
Canopy installation
Main wing installation
Model assembly
1.Install the canopy as shown.
3.Secure the left and right wings to the fuselage using the 4 screws included.
1.Slide the wing spars into the fuselage.
2.Install the left and right wing halves over the wing spars and into the wing slots.
precisely and firmly.
HKM3.0*20
A: Fuselage
B: Main wing
C: Horizontal stabilizer
D: Vertical stabilizers
E: Missile set
F: Canopy
A.
B.
C.
F.
G.
H.
I.
D.
E.
G: Carbon fiber spars
H: Screws
I : Ventral fins and pitot tubes
Notice:The connectors on both sides should be attached
