FMS F-15 - Get your model ready to fly; Important ESC and model information; The transmitter and model setup

9
3. Check the connection diagram below for more information (fig12.)
Battery and radio installation
fig12
1. Apply the hook tape to the cable end of the battery (fig 11).
2. Slide the battery into the battery compartment with the power supply cable toward the fore-end
of the plane.
Note: you may need to relocate the battery position to achieve the correct CG for your model.
fig11
