FMS F-15 - Missile Installation; Nose Cone Installation; Battery and radio installation

8
1. Apply glue on the missile with CA and slide the whole missile set into the rails on each wing (fig8/fig9).
Apply the nose cone to the front fuselage as diagram shows. Ensure the nose cone is on the correct
side.(fig10)
Missile Installation:
Nose Cone Installation:
Model Assembly
Required Adhesives:
Foam Safe Medium CA
fig10
fig8
fig9
