FMS F-15 - Clevis Installation; Landing Gear Installation

7
1. Install the main landing gear with the included screws (fig6).
2. Install the front landing gear and then tighten the screw (fig7).
Landing Gear Installation:
Model Assembly
KA2.0*8
Install the clevis. (fig5) Refer to the Clevis Installation on page 12.
Clevis Installation:
fig6 fig7
fig5
