fig4
fig3
6
Vertical Stabilizer Installation:
Horizontal Stabilizer Installation:
Model Assembly
Required Adhesives:
Foam Safe Medium CA
Carefully apply CA to the base and the side of the rear fuselage slot. Install the stabilizer into place.
Ensure the control horn faces down as shown (fig3).
Note: Ensure the stabilizer horizontal axis is parallel to the wing. Adjust any misalignment before the glue
dries thoroughly.
Carefully apply CA to the top rear fuselage slots. Install the vertical stabilizer into place (fig4).
