FMS F-35 lightning V2 - Install the Horizontal Stabilizer

6
fig3
Required Adhesives:
Medium CA
fig4
2.
With the bottom of the fuselage facing up, carefully apply CA to the base and side of the rear fuselage
slot. Install the stabilizer into place. Ensure the control horn is face up as shown (fig4).
Note: Ensure the stabilizer horizontal axis is parallel to the wing as shown (fig3). Adjust any misalignment
before the glue dries thoroughly.
