FMS F-35 lightning V2 - Assembly: Component Installation; Install Vertical Tail; Attach Nose Cone and Landing Gear

7
fig5
Required Adhesives:
Medium CA
fig6
fig7
fig8
5.
KA2.0*8
4. Apply the nose cone to the front fuselage as diagram shows. Ensure the nose cone is on the correct side
(fig7).
3. Install the vertical tail into place with glue.
Notce: the vertical tail will angle towards the outboard of the plane as picture shows.
Install main landing gear with the included screws (fig8).
