支持驱动模式设置，用于设置驱动控制模式。
驱动模式复用 CH4 通道，由 CH4 按键控制。要设置驱动控制方式，需先切换驱动控制模式。
驱动控制模式 / 四轮转向模式切换
发射机正常开机状态下，同时短按 BIND 按键和 CH4 按键，即可切换驱动控制模式和四轮转向模式，默认驱动
控制模式。
注：模式切换后，关机保存设置。
切换到驱动模式后，可设置为两驱控制或四驱控制。
功能设置：
长按 CH4 按键（≥ 2 秒 ) 切换模式。每长按控件一次切换一种模式。
发射机上的拨码开关用于设置电调参数，即拨码开关位于不同位置对应参数值不同。
该电调有三个参数项可以设置，分别是“运行模式（Running Mode）”、“电池类型 (Battery Type)”、“拖
刹力度 (Drag Brake)”。发射机面板上有一列编号为 1 2 3 4 的拨码开关，通过上下拨动可以实现对上述参数
项的设置。
The transmitter supports drive control function which is used to set drive control mode. The drive function is
controlled by CH4 channel, and the control is CH4 button. Switch to drive control function firstly, then set the
control mode.
Switching the drive control/four-wheel steering function
In the normal power-on state, press both the BIND button and the CH4 button to switch between the drive
control and four-wheel steering. The drive control is the default mode.
Note:The setting will be save when the transmitter turns off.
After switching to drive control function, you can set the drive mode between 2-wheel drive and 4-wheel drive.
Setup:
Press and hold the CH4 button over 2 senconds to switch the mode. Switch one mode per press of the control.
1. Running Mode
FWD/REV/BRK(Forward/Reverse/Brake): This mode adopts "double click" reverse mode, that is, when the
throttle trigger is pushed from netural range to the reverse area for the first time, the motor is only braking and will
not reverse; when the throttle trigger is moved back to the netural range and pushed to the reverse area for the
second time, it will reverse. This mode is applicable to general models.
FWD/REV(Forward/Reverse): This mode adopts "one click" reverse mode, that is, when the throttle trigger is
pushed from netural range to the reverse area, the motor immediately generates reverse action, which is general-
ly applied to rock crawler.
The Toggle Switch on the transmitter is used to set ESC parameters, that is, the Toggle Switch is located
at different positions and the corresponding parameter values are different.
There are three parameters can be set for the ESC, which are "Running Mode", "Battery Type" and
"Drag Brake". There are slide switches numbered 1, 2, 3, 4 on the transmitter panel. The above
parameters can be set by toggling up and down.
Toggle Switch Sign 拨码开关标识
Running Mode
FWD/REV/BRK
FWD/REV
Lipo
NiMH
0%
50%
75%
100%
Battery Type Drag Brake
18
Drive Control
驱动控制
ESC Parameters Setting
电调参数设置
System Functions
系统功能
