Connect Related Equipments
Make sure the receiver is off before connection. Then connect the motor with M+ and M- of the receiver
and connect the servo to the 3Pin interface("-", "+" and "S" are connected correspondingly). Finally,
connect the battery to the power cable interfaces of the receiver correspondingly.
Calibrate the Throttle Neutral Position
1. After connecting related equipment as above, turn on the transmitter first, then move the throttle
trigger to the neutral position.
2. Turn on the switch of receiver at last. The receiver will automatically recognize the battery type when it
is powered on again. Then it can run it.
Notes:
1. The ESC can be run after completing self-inspection (about 3 seconds) if power on, otherwise it
cannot be operated normally.
2. If there is no power output, please check whether the throttle trim of the transmitter is set to the neutral
position, the receiver will automatically recognize the neutral position of the trim throttle after restarting;
3. If the rotation direction is not correct during running, exchange the two cables connecting motor and
receiver.
4. To make sure everything is ok, please turn on the transmitter first and then the receiver, and power off
the receiver first and then the transmitter.
ESC Function Instructions
电调功能使用说明
22
Function Instructions
功能说明
车灯控制主要是通过发射机的设置实现车灯亮灯状态及亮灯模式的转换。接收机上电开机瞬间所有车灯长亮 1 秒
做自检显示。
本接收机对模型车车灯的控制预设了五种模式，各模式下模型车的倒车灯亮灭状态一致，即当模型车倒车时，倒
车灯为常亮状态，反之为常灭状态。而转向灯、前灯和车顶灯的亮灭状态各异，具体如下所述:
• 默认模式：此模式下，无论模型车是否转弯，转向灯状态为常灭状态；当倒车时，倒车灯为常亮状态，反之为
常灭状态；前灯和车顶灯为常灭状态。
• 模式 A：此模式下，当模型车转弯时，转向灯为慢闪状态；当倒车时，倒车灯为常亮状态，非倒车时为常灭状
态；前灯及车顶灯为低亮状态。
• 模式 B：此模式下，当模型车转弯时，转向灯为慢闪状态；当倒车时，倒车灯为常亮状态，非倒车时为常灭状
态；前灯及车顶灯为高亮状态。
• 模式 C：此模式下，无论模型车是否转弯，转向灯为持续慢闪状态；当倒车时，倒车灯为常亮状态，非倒车时
为常灭状态；前灯及车顶灯为高亮状态。
• 模式 D：此模式下，当模型车转弯时，转向灯为慢闪状态；当倒车时，倒车灯为常亮状态，非倒车时为常灭状
态；前灯及车顶灯为常灭状态.
注：
1. 短按发射机上的 CH4 按键切换工作模式，每按一次，切换一个模式（默认模式、模式 A、模式 B、模式 C 和
模式 D 依次切换）；
2. 每次开机时，车灯控制模式为默认模式；
3. 模式 C 为应急灯工作状态，左右转向灯同时同步慢闪做应急灯；
4. 本接收机上电自动识别方向 CH1 和油门 CH2 的通道中位。当发射机调了微调后，建议重启一下接收机。
