The receiver has a built-in antenna. In order to ensure the
signal strength and avoid the remote control distance affected,
when installing the receiver, you need to pay attention to the
followings:
•The receiver antenna must be kept perpendicular to the model
body (as shown in the picture)!
• It is recommended to install the receiver on a high level
surface of the model body without metal obstructions around
the receiver.
18
Receiver Specifications
接收机规格
Installation
安装说明
本款接收机为内置天线，为保证信号强度，以免影响遥控距离，安装
接收机时，需注意以下事项：
•接收机天线须与模型机身保持垂直（如图所示）！
•建议将接收机安装在模型机身位置较高的水平面上，且四周无金属
遮挡。
产品型号：FS-FMS-R4P1-BS
适配发射机：FS-FMS-G4P-BS、FS-FMS-MG4-BS、
FS-FMS-MG6-BS
适配模型：车
PWM 通道数：3
无线频率：2.4GHz ISM
无线协议：2A-BS
天线类型：内置单天线
遥控距离：> 150 米 ( 空旷无干扰地面距离 )
车灯组数：6（LED 车灯接口连接 DB01 车灯驱动板 )
工作电压：3.5 ~ 8.4V/DC
数据输出：PWM
温度范围：-10℃ ~ +60℃
湿度范围：20% ~ 95％
防水等级：PPX4
在线更新：无
外形尺寸：22.6*20.6*25.5mm
机身重量：6g
• 认证： CE, FCC
Product Model: FS-FMS-R4P1-BS
Compatible Transmitters:
FS-FMS-G4P-BS,FS-FMS-MG4-BS,
FS-FMS-MG6-BS
Compatible Model:Cars
Number of PWM Channels: 3
RF: 2.4GHz ISM
RF Protocol: 2A-BS
Antenna: One bulit-in antenna
Distance: More than 150m (Ground distance
without interference)
Operating Voltage: 3.5 ~ 8.4V/DC
Number of Car Light Connectors: 6 (DB01 Car
light control board connects to the LED car light
connector)
Data Output: PWM
Temperature Range: -10℃ ~ +60℃
Humidity Range: 20% ~ 95%
Waterproof: PPX4
Online Update: None
Dimensions: 22.6*20.6*25.5mm
Weight: 6g
Certifications: CE, FCC
内置天线 /
A Built-in Antenna
FS-FMS-R4P1-BS 接收机 /
FS-FMS-R4P1-BS Receiver
