A.
B.
C.
D.
F.
E.
G.
A: Main fuselage
B: Main wing(Left and Right)
C: Horizontal stabilizer
D: Vertical stabilizer
Nose cone and Drop tank
Screws (2-HKM3.0*32MM,4-HKM3.0*16MM)
Wing tube
Before assembly, please inspect the contents of the kit. The photo below details the contents of the kit and
labels. If any parts are missing or defective, please indentify the name or part number (refer to the spare
parts list near the end of the manual) then contact your local shop or email us: support@fmsmodel.com
Contents of Kit
4
Wingspan: 880mm (34.6in)
Overall Length: 1060mm (41.7in)
Flying Weight: Around 1850g (65.3oz)
Motor Size: Brushless 2860-KV1850
Wing Load: 100 g/dm² (0.23oz/in²)
Wing Area: 19 dm² (294.5 sq.in)
ESC: 70A
Servo: 9g Servo x 8
