FMS YAK-130 - Wing Installation

AIL
AIL
FLAP FLAP
7
1.
2.
3.
Wing Installation
Connect the Aileron servo connectors to the servo extensions in the fuselage.
Slide the tube into the fuselage then install both wings over the wing tube and into the wing slow of the
fuselage (fig5).
Secure the left and right wings into the fuselage using the included 4 screws (fig7).
fig6
fig7
fig5
HKM3.0*16
