4-15
Group 03 External Digital Input and Output Parameters
Param.
#
Parameter Name Setting Range Default Unit
Control mode
Notes
V/F SLV PM/SLV
03-13 Freq. Detection Level 0.0–599.0 0 Hz
03-14 Freq. Detection Width 0.1–25.5 2 Hz
03-15 Current Agree Level 0.1–999.9 0.1 A
03-16
Current Agree Detection
Delay Time
0.1–10.0 0.1 s
03-17
Mechanical Braking
Release Level
0.00–599.00 0 Hz
(Note)
03-18
Mechanical Braking
Level Set
0.00–599.00 0 Hz
(Note)
03-19 Relay (R1A-R2A) Type
xxx0b: R1 A Contact
xxx1b: R1 B Contact
0000b -
xx0xb: R2 A Contact
xx1xb: R2 B Contact
03-20
Internal / External Multi-
Function Input Terminal
Selection
0–63 0 -
03-21
Action To Set The
Internal Multi-Function
Input Terminals
0–63 0 -
03-22 Pre-Set Count 1 0–9999 0 -
03-23 Pre-Set Count 2 0–9999 0 -
03-24
Output Under Current
Detection
0: Invalid
0 -
1: Valid
03-25
Output Under Current
Detection Level
0–999.9 0.1 A
03-26
Output Under Current
Detection Delay Time
0.0–655.34 0.01 s
03-27
UP/DOWN Frequency
Hold/Adjust Selection
0: Hold last set frequency when
stopped
1: Set frequency to 0 when stopped
2: Allow speed changes from last set
frequency when stopped
3: Refresh frequency at acceleration.
0 -
03-30 Pulse Input
0: General Pulse Input
0 -
1: PWM
03-31 Pulse Frequency 50–25000 1000 Hz
*1
03-32 Pulse Input Gain 0.0–1000.0 100 %
*1
03-33 Pulse Input Bias -100.0–100.0 0 %
03-34 Filter Time of Pulse Input 0.00–2.00 0.1 Sec
03-40
UP/DOWN Frequency
Width Setting
0.00–5.00 0.00 Hz
03-53 Current Agree Level 2 0.1–999.9 0.0 A
03-17 to 03-18: If the maximum output frequency of motor is over 300HZ, the frequency resolution is changed to
0.1Hz
*1: Parameter can be changed while running.
