2. Model Description
2.1 Nameplate Data
Unpack the TD400 AC Drive and check the following:
(1) The TD400 AC Drive start-up and installation manual (this document) is contained in the package.
(2) The TD400 AC Drive has not been damaged during transportation; there should be no dents or missing parts.
(3) The TD400 AC Drive is the type you ordered. You can check the type and specifications on the main nameplate.
(4) Check that the input voltage range meets the input power requirements.
(5) Ensure that the motor HP matches the motor rating of the AC Drive.
(1HP = 0.746 kW)
Product Name and Motor Ra琀ng
Input Power Specifica琀ons
Output Power Specifica琀ons
Series No
UL and CE Marks
PRODUCT: E510-2P5-H-U MOTOR RATING: 0.5 HP
INPUT : AC 1/3PH 200-240V (+10%,-15%) 50/60hz 8.5/4.5A
OUTPUT : AC 3PH 0-599 Hz 3.1A IP20/NEMA 1
ENCLOSURE : IP20
P/N BARCODE S/N BARCODE
TD400-20P5-13PH
TD400 AC Drive Series
TD400 - 20 10 - 1PH
20:
40:
200-240V
380-480V
Input Voltage Ra琀ng
Motor Ra琀ng
1:
13:
3:
1Ph
1Ph or 3Ph
3Ph
Input
P5: 0.5 HP
01: 1 HP
02: 2 HP
03: 3 HP
05: 5 HP
08: 7.5 HP
10: 10 HP
15: 15 HP
20: 20 HP
30: 30 HP
40: 40 HP
50: 50 HP
60: 60 HP
75: 75 HP
