FNM HPE Series User Manual

118 FNM
®
HPE Series
Display views
Status
Meaning
Above 90 ° C
Indicates an operating temperature too high. If the needle remains above
90 ° C for a long time the "High Engine Temp! Critical” alarm turns on
together with the buzzer and the warning lights. Turn off the engine
immediately and check the coolant level.
Glow plugs
indicator light (if
present)
Lit, engine off
It indicates the glow plugs preheating required to properly start the
engine.
Blinking
Indicates a critical engine failure. Contact a FNM
®
service point to make
the diagnosis.
Transmission oil
anomaly indicator
light
Off
Indicates normal operation
On, stern drive or gearbox
installations
Indicates the low level of oil in the transmission. Check and fill the
transmission system with proper lubricant, then start the engine again. If
the problem persists, contact an authorized FNM® service point.
On, Saildrive installations
Indicates leakage of seawater from the Saildrive seals. Check the seal
status.
Alarm:
CHECK ENGINE!
Displayed
Indicates a failure of the engine. At the same time the alarm buzzer of
the panel turns on. The reason for which the indicator light turns on can
be:
- Problem on injection system
- ECU malfunction
- Engine over heating
Make a diagnosis at a FNM
®
authorized service point.
Alarm:
ENGINE
EMERGENCY
STOP!
Displayed
Indicates a serious malfunction of the engine. At the same time the
alarm buzzer of the panel turns on.
Turn off the engine immediately and check it. Make a diagnosis at a
FNM
®
authorized service point.
