Focal SCALA UTOPIA User Manual

09
Fine Tuning
The global speaker: linear nominal response
6
4
2
0
-2
-4
-6
2010
30
50
100
200
300
500
1k
2k
3k
5k
10k
40kHz
20k
Setting for:
- Normal room, but with the sub-bass band recessed due to cancelling standing waves.
- Plaster plate walls, absorbing the sub-bass band.
- Electronics sounding recessed in the LF band.

Focal SCALA UTOPIA Specifications

General

Type	3-way floorstanding speaker
Frequency Response	27Hz - 40kHz
Sensitivity	92dB
Power Handling	500W
Recommended Amplifier Power	40 - 500W
Nominal Impedance	8 Ohms
Minimum Impedance	3.1 Ohms
Drivers	1 x 1" Beryllium tweeter, 1 x 6.5" Power Flower midrange, 1 x 11" W cone woofer
Dimensions	670 mm (26.4")
Weight	85kg (187lbs)
