Focal SUB ONE User Manual

8
SUB ONE
™
User manual
EN
System SUB ONE
• Frequency response (+/- 3dB) 32Hz - 120Hz
• Maximum SPL 114dB SPL (peak @ 1m)
Electronic section
• Inputs - Type / Impedance
- Connector
- Sensitivity
Left, Right, LFE
Electronically balanced / 110kOhms
3-point female XLR
Variable
• Outputs
(to satellites)
- Connector Left + Right
3-point male XLR in parallel on inputs
• Amplification 2 x 100W RMS, D-class
• Internal signal processing
and functions
- Subwoofer section Left + Right mono summation
60Hz or 90Hz high-pass crossover
Adjustable low-pass crossover, 24dB/octave
Phase adjustment
Polarity
• User controls Subwoofer level adjustment (sensitivity)
Low-pass crossover cut-off frequency adjustment
Phase adjustment
Polarity inverter
Mute
External mute (controlled by a pedal)
• Indicators (LED) Power
Defeat
• Power supply - Local supply
- Connection
Universal power Detachable
IEC inlet power cord
Transducers
• Subwoofer 2 x 8'' (20cm) long-excursion
Focal speaker drivers with Slatefiber cones
Cabinet-work
• Construction 7/8" (22mm) MDF panel with internal braces
• Finish Dark grey vinyl
• Dimensions (HxWxD) 18
3/4
"x11
3/4
"x19
3/4
"
(475x310x520mm)
• Weight 40.8lbs (18.5kg)
