Follett FZR20-LB - User Manual

Questions and Answers

K
Kimberly MillerAug 5, 2025
What to do if Follett Freezer does not maintain temperature?
- T
  Toni HowardAug 5, 2025
  If your Follett Freezer isn't maintaining the correct temperature even when all components are running, several factors could be the cause. Start by cleaning the condenser coil. Ensure the door is closing properly, adjusting as needed. Be mindful of the ambient temperature, keeping it below 86°F (30°C). Check for refrigerant leaks and repair if necessary. If the refrigerant charge is incorrect, recover, evacuate, and weigh in the correct charge. Also, inspect the TXV for restrictions or faults and replace if needed. Replace the door gasket if it's faulty. If ice accumulates in the top air return, defrost it completely.
B
Brenda BennettAug 10, 2025
Why my Follett FZR20-LB does not operate?
- K
  kaitlyn19Aug 10, 2025
  If your Follett Freezer isn't operating at all, first, ensure the power switch is in the ON position and check for any loose connections. Verify that the freezer is properly plugged into the outlet. Make sure there is power at the outlet and that the voltage is correct. Check the temperature controller contact terminals for power, replacing the controller if necessary. Lastly, if the probe isn't sensing the cut-in temperature, replace the controller and/or probe.
R
Randall WilliamsAug 17, 2025
What to do if Follett FZR20-LB Freezer does not shutoff?
- M
  Mrs. Kelly Goodman DDSAug 17, 2025
  If your Follett Freezer won't shut off, the controller might not be sensing the cut-out temperature. In this case, replace the controller and/or probe. It's also possible that the controller is keeping the refrigeration system energized, so replacing the controller might be necessary.
T
Timothy CummingsAug 22, 2025
Why Follett FZR20-LB compressor does not run?
- B
  Brittany MaloneAug 22, 2025
  If the compressor in your Follett Freezer isn't running, the thermal overload might be open or defective. Allow it to cool or replace it. The capacitor and/or relay could also be defective, requiring replacement. In some cases, the compressor itself might be defective and need replacement. Additionally, the HP switch could be open or faulty; allow it to cool or replace it.
J
Justin JenkinsAug 29, 2025
How to fix Follett Freezer evaporator fan motor that does not run?
- J
  Jonathan FreemanAug 29, 2025
  If the evaporator fan motor in your Follett Freezer isn't running, it's likely that the fan motor is defective and needs to be replaced.

Summary

Welcome to Follett

Before You Begin

Inspect equipment for damage after uncrating and check configuration numbers for unit details.

Specifications

Ambients

Intended for indoor use, ambient temperature not exceeding 86°F (30°C) and humidity not exceeding 60% RH.

Clearances

Required clearances for proper ventilation: 16 inches above, 2 inches behind, 9 inches on left side.

Electrical Specifications

Unit uses 120V, 60Hz, 1 phase power with specific ampacity and circuit requirements.

Refrigeration Specifications

Uses R404a refrigerant (10.6 oz / 300 g) and has specific operational parameters.

Detail Drawing

Provides visual representation and dimensions of the freezer unit with required clearances.

Installation

Adjust Self-Closing Door

Instructions on how to adjust the door for proper tension and alignment for a positive close.

Install Shelves and Power Up

Guide for installing shelves and connecting the unit to a power source.

Fill Product Simulation Bottle

Remote Alarm Connections

Third-Party Probe Wire Routing

Operation

Quick Setup Checklist

A step-by-step guide for initial unit setup, including time/date and alarm settings.

Set Time and Date

Change Temperature Display

High and Low Alarm Setup

Alarms

Alarm Muting

How to temporarily silence audible alarms using the MUTE button for specific increments.

Alarm Volume Selection

Guide to adjust the audible alarm volume to high, medium, or low settings.

Alarm Silence

Procedure to turn audible alarming on or off via the menu interface.

Password PIN Security

Cleaning

Interior Cleaning

Guide for cleaning the inside of the unit using a non-abrasive detergent.

Exterior Cleaning

Instructions for wiping down the stainless steel exterior and glass door.

Annual Cleaning and Inspection

Service

Refrigeration System

Overview of the refrigeration system, its components, and maintenance requirements.

Defrosting

Explanation of the automatic timed defrost cycles and termination conditions.

Controller Operation

Temperature Sensor Readings

Fascia Heater Cycle

Door Heater Cycle

Changing Temperature Set Point

Defrost Settings

Test Defrost;Manual Defrost

Facade Removal

Evaporator Cover Removal and Reinstallation

Controller Replacement

Door Gasket Replacement

Slide-out Unit Cooler

Wiring Diagram

Troubleshooting

Before Calling for Service

Basic checks to perform before contacting technical support for issues.

Appendix

Control Key Functions

Explanation of the functions of the control panel buttons (Menu, Enter, Mute, etc.).

Menu Navigation Table

Overview of menu options, submenus, default settings, and ranges for configuration.

Replacement Parts

Unit Cooler

Illustrated diagram of the unit cooler assembly with part references.

Cabinet

Facade

Door Assembly

Follett FZR20-LB Specifications

General

Model	FZR20-LB
Type	Freezer
Capacity	20 cu. ft.
Weight	250 lbs
Power Supply	115V
Voltage	115V
Hertz	60 Hz
Power Source	Electric
Depth	34"
Height	60.25"
Phase	1 Phase
Door Type	Solid
