DESCRIPTION
- Enjoy your favourite channels on this HD DVB-S2 satellite receiver that offers great reception and
image quality. It features two USB ports so you can play media files (MPEG-4/MPEG-2/MPEG-1),
record your favourite programs, or pause and watch them again at any time (Timeshift function).
- Multi-language, intuitive and easy to use menu HD output up to 1080p over HDMI and SD standard
definition over europlug.
- It supports high-efficiency video encoding (H.264/MPEG-4 AVC) and Dolby D+, Dolby Digital.
- Save, export and edit channels (Favourites, Move, Parental Lock, Delete and Sort). It has a pre-loaded
channel list and can be updated over the network (OTA).
- Broaden the reception of channels on your TV.
CONTROLS AND FUNCTIONS
FRONT PANEL
RDS-524HD
DVB-32 SATELLITE RECEIVER
1.- Information display.
2.- Connection port for USB storage devices.
3.-
: button to switch the receiver on/off.
4.- +/-: volume adjustment buttons.
5.- M: displays the main menu on the screen.
6.- </>: buttons for channel switching and navigation. These allow you to scroll through the different menu
options.
7.- OK: confirmation key.
REAR PANEL
RDS-524HD
DVB-32 SATELLITE RECEIVER
5
1
4
2
3 6 7
1 2 4 5
6
3
1.- LNB IN: input for the parabolic antenna signal tuner (LNB), Female F connector.
2.- USB: USB port for connection of USB storage devices. For recording, playback of content (video,
music or image) or a Wi-Fi adapter.
NOTA: this device is compatible with USB WiFi adapter RT5370.
3.- COAXIAL: digital audio output, RCA connector.
4.- HDMI: high-definition (HD) audio and video output for connection to a TV with digital input. The output
resolution is configurable via the AV SETTINGS/SETTINGS menu.
5.- TV: standard definition (SD) audio and video output to connect to the TV input.
6.- Receiver power supply input 100/240 V.
NOTE: disconnect the equipment from the power supply when it is not to be used for a long period of time.
