Installation of PowerPack - Model 1 & 2
1. Insert the key, and turn anticlockwise to the saddle latch release position
2. Remove key from ignition
3. Lift the saddle
4. Release PowerPack cover by turning white locking mechanism clockwise
5. Lift PowerPack cover
6. Ensure PowerPack safety switch is set to the OFF position (right, toward the back of the PowerPack and
the scooter)
7. Insert the PowerPack into the holding bay
8. Connect power Connector (blue colour).
9. Set safety switch to ON position (left, toward front of the PowerPack and scooter)
10. Close PowerPack cover
11. Return locking mechanism anticlockwise to lock cover in place
PowerPack
For a longer service life, prevent arcing wear and tear on the Power
Connector by turning the Safety Switch to OFF position when the Power
Connector is being connected / disconnected. You can also minimise
sparking by ensuring the ignition is turned to OFF.
TIP
