Fonzarelli Arthur - Charger; Charger features; Charger Operation

15
Charging Indicator :
Caution:
DC Output Wire :
LED1 Red: Power On
LED2 Red: Charging
LED2 Green: Charged
Battery Type:
AC Input :
Battery Voltage(V): Charge Current(A):
F M A
L
90-120Vac
12
72
24
84
36
96
48 68
108
220-240Vac 100-240Vac
Brown:
Blue:
H W
3
8
4
10
5
12
6 7
Do not e xpose to wate r, volatile gas
or opened
ame.
Charge in a well- ventilated ro om.
The case of the charger is the heat
sink; do not co ver it.
ATE
OK
20
15
HI-POT
OK
Charger features
If you are not riding the bike for extended periods of
time, you should leave the charge % between
60-90%. In case of malfunction, please contact
cusomer support immediately.
Warning! Never store the PowerPack at 0%.
Constant Current & Voltage (CC & CV)
Multi-Stage Charging
Built-in Microcontroller (MCU)
Pulse Width Modulation (PWM)
LLC Resonance and Synchronous Rectification
Charger Operation
Make sure the charger is firmly connected to the
Powerpack.
The charger will be turned off automatically after
the Powerpack is fully charged. Unplug the charger
from AC outlet when the charger is not in use.
Some chargers are not designed to be carry
onboard the vehicle. Please make sure the voltage
from AC outlet matches that required by the
charger. Fonzarelli is not responsible for any
improper operations.
Notes: Unplug the charger from AC outlet before
unplugging the Powerpack.
Notes: Plug the charger into the Powerpack after
plugging into the standard AC outlet.
LED Display Fuse On/Off switch
Charger
IMPORTANT
60 - 90%
