Foppapedretti Rolling Fix - USING OF THE CHILD CAR SEAT; 4-2 HARNESS ADJUSTMENT

• ENGLISH •
35
USING OF THE CHILD CAR SEAT
4-2 HARNESS ADJUSTMENT
Loosen: Press adjusting button 16 and
at same time pull both shoulder strap
5 forwards.
IMPORTANT: Do not pull on the
shoulder pads 3.
CAUTION:
Adjusting button 16 with miss operation function, please operate correctly
according to the picture.
Tighten: Pull on the adjustment strap 15 until the
harness lies at and is close against your child’s body.
Checking with your 1 nger gap between harness
and your child’s front shoulder point. Make sure your
child is comfortable and secured.
CAUTION:
Grasp the both shoulder straps 5 by one hand
(with index nger and middle nger), and pull the
adjustment strap 15 forwards with another hand
slowly, when the hand with shoulder strap touch with
child body then stop pulling the adjustment strap 15
, the strength of shoulder strap is properly.
USING OF THE CHILD CAR SEAT
3
5
16
15
5
15
3
5
16
15
5
15
3
5
16
15
5
15
