CUTTING HEIGHT
Pull out the height adjustment
lever14 and the desired cutting
depth.
LOWER HANDLE
Move the lower handle12 to an
upright position and close the
lower locking lever5.
SAFETY PLUG
Insert the safety plug directly
before starting and remove it
when interrupting or terminat-
ing the work.
CONTROLS
In order to switch the appli-
ance on, press and hold the
safety button 1, tilt the appli-
ance backwards, pull the on/o
triggers2 or 10 and release the
safety button1.
COLLECTION BAG
Lift the safety flap 4 and at-
tach the collection bag13 to the
mower.
If the collection bag 13 is se-
curely attached to the mower,
lower the safety flap4.
Caution! Never use the appliance with open locking levers.
Caution! Make sure the appli-
ance is switched o and the
battery is removed.
Caution! Never run the appli-
ance without collection bag
in place.
Caution! Wait until the blade
has come to a complete stop
before opening the safety flap.
Observe the rotation direc-
tion when replacing the blade.
Tighten the fastening screw A.
REPLACING THE BLADE
Loosen the fastening screw A
and remove the worn blade.
Caution! Switch o and re-
move the battery first. Al-
ways use protective gloves.
Warning! The blades should
only be replaced by author-
ized persons.
UPPER HANDLE
Install the upper handle 11 to
the lower handle12 as shown,
using the upper locking lever3
assembly.
BATTERIES
Lift the battery cover 7 and
push the battery (not included)
in until it clicks into place.
