Page 3 of 15 ENG 0019.14 Part # 93030
Minimum Clearances to Overhead Cabinets
30" (762mm) minimum clearance between the top of the cooking surface and the bottom
of an unprotected wood or metal cabinet;
or
24” (610mm) minimum when bottom of wood or metal cabinet is protected by a flame
retardant heat shield.
To eliminate the risk of burns or fire by reaching over the heated surface, cabinet storage
space located above the surface units should be avoided. If cabinet storage is to be
provided, the risk can be reduced by installing a range hood that projects horizontally a
minimum of 5" beyond the bottom of the cabinets
Gimbal Installation
Cutout Dimensions:
Mount a gimbal wall plate bracket on each side of the opening as shown in the diagram.
This will position the stove so that the top of the cooking grill frame is flush with the
countertop and the front of the unit will be flush with the front surface of the adjacent
cabinets.
Level each gimbal wall plate bracket and fasten with four #12 wood screws at least 1/2”
(13mm) in length. (Screws not included)
Drill a 3/8” (10mm) hole on each side of the opening for the gimbal pin. Locate the hole
in the position shown in the diagram. Fasten the gimbal lock plate over the hole using
two # 8 wood screws at least 3/8” (10mm) in length. (Screws not included)
Carefully lift the stove into position so that the gimbal knobs slide into the brackets.
Gently push the safety tabs of the bracket inward, toward the stove so that they protrude
over the gimbal knobs.
Model Description A B C D E F G H
63251
2 - Burner NA Standard
22” 19” 23 ¼” 2” 2 ⅜” 5” 5⅛” 6 ⅜”
63253
2 - Burner NA Compact
22” 19” 21” 2” 2 ⅜” 5” 5⅛” 6 ⅜”
63254
2 - Burner European Sub Compact
18½” 15 ½” 21” 2” 2 ⅜” 5” 5⅛” 6 ⅜”
63256
2 - Burner European Standard
20 ⅜” 19” 23 ¼” 2” 2 ⅜” 5” 5⅛” 6 ⅜”
63258
2 - Burner European Compact
20 ⅜” 19” 21” 2” 2 ⅜” 5” 5⅛” 6 ⅜”
63269
2 - Burner XM
19 ½” 19” 22” 2” 2 ⅜” 5” 6” 7 ¼”
63351
3 - Burner NA Standard
22” 21” 23 ¼” 2” 2 ⅜” 5” 6 ¾” 8”
63353
3 - Burner NA Compact
22” 21” 21” 2” 2 ⅜” 5” 6½” 7¾”
63354
3 - Burner European Sub Compact
20 ⅜” 19 ¾” 19 ½” 2” 2 ⅜” 5” 6¼” 7½”
63356
3 - Burner European Standard
20 ⅜” 21” 23 ¼” 2” 2 ⅜” 5” 6 ¾” 8”
63358
3 - Burner European Compact
20 ⅜” 21” 21” 2” 2 ⅜” 5” 6½” 7¾”
63451
4 - Burner NA Standard
22” 21” 23 ¼” 2” 2 ⅜” 5” 6 ¾” 8”
63453
4 - Burner NA Compact
22” 21” 21” 2” 2 ⅜” 5” 6½” 7¾”
