Page 4 of 15 ENG 0019.14 Part # 93030
Make sure the stove swings freely at least 15 degrees. Check to ensure the gimbal lock
pins slide into the hole.
Built-in Installation
Cutout Dimensions:
Model Description A B C
73251
2 - Burner NA Standard
20¾” (527mm) 16” (407mm) 22 ¼” (565mm)
73253
2 - Burner NA Compact
20¾” (527mm) 16” (407mm) 20” (508mm)
73351
2 - Burner European Sub Compact
20¾” (527mm) 20” (508mm) 22 ¼” (565mm)
73353
2 - Burner European Standard
20¾” (527mm) 20” (508mm) 20” (508mm)
73451
2 - Burner European Compact
20¾” (527mm) 20” (508mm) 22 ¼” (565mm)
