(See Chapter "FIELD CALIBRATION, SET-UP CODE 9081")
Allows you to choose between "lbs per day" ("gallons per day") and "lbs. per hour" ("gallons per hour") and allows you
to set your sample time or "update period" for your feed rate function.
Use ARROWS to select:
Rate Update Period In: MIN = Minutes
HOUR = Hours
PERIOD BASE
____MIN ____ HOUR
Action Required - Press "ENTER" after completing each step
Digital Display / Default (in red)
In general, if your feed rates are fairly constant on a daily basis, the longer you set your update period for, the more
accurate your feed rate function will be. However, if your feed rate varies from hour to hour or minute to mintue, choose
a shorter update period to give you a more accurate feed rate at a point in time. You may have to experiment with
different update periods to get the desired result for your application.
*IMPORTANT NOTE: Setting your "Update Period"
For certain applications with very low feed rates (less than 2% of full scale capacity per day), low sample times will not
give you accurate readings.
RATE TIME BASE
____PPH ____ PPD
____KPH ____ KPD
This function allows you to choose your display to read in weight or gallons. If you choose gallons, you must enter
the specific gravity of the chemical being fed.
UPDATE PERIOD
HOURS = _________
Use ARROWS to select update period:
Choice if HOURS: 2, 4, 6, 8, 12 Hours
Choice if MINUTES: 2, 5, 10, 20, 30, 60 Minutes
NOTE: See IMPORTANT NOTE above "Setting your Update Period".
DISPLAY UNITS
*LBS. GAL
*KGS GAL
Use ARROWS to select WEIGHT (Lbs/Kgs) or VOLUME (Gallons).
SPECIFIC GRAVITY
SCALE 1 = X.XXX
If you choose VOLUME, enter the specific gravity of material being fed.
NET REMAINING
SCALE 1 = X.XXX
Displays the result of the above selections.
Digital Display / Default (in red)
Action Required - Press "ENTER" after completing each step
Use ARROWS to select: (If Lbs chosen) (If Kgs chosen)
If calibrated in LBS/KGS: PPH = Lbs. per HOUR KPH = Kgs. per HOUR
PPD = Lbs. per DAY KPD = Kgs. per DAY
Or if calibrated in GALLONS: GPH = Gallons per HOUR
GPD = Gallons per DAY
Use a Longer
Update Period
9083 DISPLAY UNITS
9082 FEED RATE FORMAT
9081 FIELD CALIBRATION
HIGH FEED
CONSTANT
LOW FEED (less than 2% capacity/day)
N/A (Not Accurate)
Use a Short
Update Period
Use a Short or
Long Update Period
FLUCTUATING
1150-D Burnett Ave, Concord, CA 94520 USA
1-800-893-6723 US & Canada, Fax: 925-686-6713
www.forceflow.com / info@forceflow.com
File: T4\O&M\AWZMSTR\WZSETUP2.tcw (B14.pdf)
QUESTIONS ? Help Hotline: 1-800-893-6723
