Force F-X15-V2 - Page 17

9
10
14
14
8
11
10
11
10
8
15
10
9
14
Front External Base Fixing Plate - Left
1
15
Front External Base Fixing Plate - Right
1
8
T-shaped Fixing Plate
T6
2
11
Lock Nut
M16 8
10
Flat Washer
φ17×φ40×3 16
9 Hexagon Bolt
M16×110
8
ASSEMBLY STEP 4
Key No.
Description
Note Quantity
16
F-X15-V2
