Force F-X15-V2 - Page 21

29
27
28
10
10
11
26
25
26
25
11
10
10
28
25
Flat Washer
φ10
4
26
Hexagon Bolt
M10×95
4
27
Upper Frame - Right
1
11
Lock Nut
M16
2
10
Flat Washer φ17×φ40×3
4
28
Hexagon Bolt
M16×105
2
29
Upper Frame - Left
1
Key No. Description Note
Quantity
ASSEMBLY STEP 8
20
F-X15-V2
