Force F-X15-V2 - Page 38

39
25
37
107
25
40
108
107
Weight Pulley Bracket
1
37
Pulley (96mm)
φ92 1
39
Hexagon Bolt
M10×45
1
40
Lock Nut
M10
1
25
Flat Washer
φ10
2
108
Hexagon Nut
M12 1
Key No. Description Note
Quantity
EXPLODED DIAGRAM
20.Weight Stack Pulley Frame, 2 pcs
37
F-X15-V2
