Force F-X15-V2 - Page 44

83
84 86
85
83
Foot Plate Bracket Weldment
1
84
Reducer Sleeve
□50×50/45×45
1
85
Umbrella Pin
φ12×M20×40
1
86 Square Tube Inner Plug □60×60×2
1
Key No. Description Note
Quantity
EXPLODED DIAGRAM
53.Low Row Foot Plate Support Frame, 1 pc
43
F-X15-V2
