1
Base Frame - Left
1
2
Rear Upright
2
3
Hexagon Bolt
M12×25
10
4
Flat Washer φ12
10
5 Spring Washer
φ12
10
6
Base Frame - Right
1
7
Rear Base Frame
1
8
Rear Base Fixing Plate
T6
4
9 Hexagon Bolt
M16×110
30
10
Flat Washer
φ17×φ40×3
74
11
Lock Nut
M16 36
12
Front Upright - Left (silver)
1
13
Front Upright - Right (silver)
1
14
Front External Base Fixing Plate - Left
1
15
Front External Base Fixing Plate - Right
1
16
Pulley Slider - Left
1
17
Pulley Slider - Right
1
18
Weight Stack Guide Rod
4
19
Weight Stack (Includes Top Weight Plate)
2
20
Weight Stack Pulley Frame
2
21
Rubber Bumper - Weight Stack
φ60×φ27×42
4
22
Weight Stack Selector Pin
φ10×100
2
23
Weight Stack Locking Shaft
φ17.8×17-M12
4
24
Internal Hex Column Screw
13×30-M10
4
25 Flat Washer
φ10
48
26
Hexagon Bolt
M10×95
4
27
Upper Frame - Right
1
28
Hexagon Bolt
M16×105
8
29
Upper Frame - Left
1
30
Logo Board
1
31
Rear External Top Fixing Plate
T6
2
32
Front External Top Fixing Plate - Left
1
33
Front Internal Top Fixing Plate
T6
2
34
Front External Top Fixing Plate - Right
1
35
Chin Up Frame
1
36
Pulley Cover
T3
12
37
Pulley (96mm)
φ92
22
38
Spring Washer
φ10
18
39
Hexagon Bolt
M10×45
12
PARTS LIST
Key No.
Description Note Quantity
50
F-X15-V2
