116
Sliding Sleeve Right
1
117
Ground Tube Left
1
118
Countersunk Hexagon Rivet Nut
M12
8
119
Barbell Bar Protection Bushing
φ63*5.8×175
2
120
Ground Tube Right 1
121 Upper Beam Right Weldment
1
122 Square Tube Inner Plug □75×75×2.5 2
123
Upper Beam Left Weldment
1
124
J Hook Right Weldment
1
125 J Hook Rollar φ40*88
2
126
Deep Groove Ball Bearing
6000
4
127 Rubber Sheet φ190×45×7
2
128
Hexagon Socket Button Head Screw
M10×115
2
129 Countersun
k Hexagon Screw
M6×12 12
130
J Hook Front Rubber Sheet
12.3*96 2
131
Lat Pull Down Bar Bent Tube
φ25*2 1
132 Handgrip Outer Stop Collar
φ31.5×φ25.5
2
133 Two Layer Spring Nut φ23-M8
2
134 Lat Pull Down Bar Hanging Plate T6 1
135 Lat Pull Down Bar Stop Collar
φ39×φ26×12
2
136
Handgrip Internal Stop Collar φ33×φ26×10.5
2
137
Dip Plastic Handgrip φ25*480
2
138 Internal Hexagon Sunk Lock Screw M6*6
6
139
Countersunk Cross Recessed Screw M8×2
0
2
140 Grub Screw M4×3
4
141 Straight Bar 1222
Aluminium Alloy
1
142 Spring Stop Collar A
28
2
143 Screw 1
144
Internal Thread Shaft
φ17*38 2
145
Gasket
φ33*φ12.5*T3
2
146
Deep Groove Ball Bearing
6001-2RS 2
147
Bearing Sleeve φ33*φ22 2
148
T-shaped Cotter Pin
φ9.4*φ6.3 2
149
Cotter Pin Bushing φ13*φ9.45 4
150
U-shaped Fastener
2
151
Stop Collar
5 2
152
Hexagon Socket Button Head Screw M8×16 2
153
Spring Gasket
φ8 2
154
Flat Gasket
φ8 2
155
J-hook Left
1
PARTS LIST
Key No.
Description
Note
Quantity
53
F-X15-V2
