EXCHANGE BETWEEN T-RAIL AND C-RAIL
STEP1: Take off the sprocket bearing base.
STEP2: Fix the motor shaft sleeve and then attach the C-Rail to the opener.
STEP3: Assemble the 2 “U” Hanging brackets with 6mm nuts supplied.
STEP1: Take off the 2 “U” Hanging brackets.
STEP2: Take off the motor shaft sleeve and C-Rail one by one.
STEP3: Assemble the sprocket bearing base and fix with M6*14 screws supplied. STEP4:
Attach the T-Rail to the opener and fix with M8*12 self-locking bolts supplied.
STEP5:
Align
the chain on the sprocket, and then following details please view previous Sectional Steel T-
Rail Assembly Guides.
