7
8
7 Flat Washer φ10 10
8 Lock Nut M10 4
24
Chin Up Frame
1
25
Hexagon Bolt
M10×80 6
ASSEMBLY STEP 8
Key No.
Description
Note
Quantity
20
F-G12-V2
