Force G12-V2 - Page 29

60
59
25
56
7
8
53
25
57
58
8
55
54
53
56
55
58
25
25
53
53
8
7
8
7 Flat Washer φ10 16
8 Lock Nut M10 8
25 Hexagon Bolt M10×80 4
53
Pulley (96mm)
φ92 6
54
Cable Guide
T4 2
55 Hexagon Bolt M10×50 2
56
Metal Bushing
Φ20*φ16*φ10.5*20.5 8
57
Pulley (75mm)
φ75 2
58 Hexagon Bolt M10×45 2
59
Floating Pulley Frame
2
60
Weight Stack Cable
6400mm 2
ASSEMBLY STEP 16
Key No.
Description Note Quantity
28
F-G12-V2
