Force JX-DS913 - Step 12: Leg Developer Final Assembly

Assembly Instructions
Step 12
Attach the Leg Developer(7#) to the bracket and secure it with 1pc Axle(62#),2pcs
φ
10 washer
(73#),2pcs M10×25 Allen Bolt(66#).
Insert the 2pcs Foam Roll tube(23#) as the diagram shows. And push 4pcs form roll(28#)from both
ends and then push 4pcs End Cap (80#) again .
17
