Sectional Steel Track Assembly
1. 2-Parts Track:
As Fig.6, slide the A rail into the sleeve, slide the B rail into the sleeve.
3-Parts Track:
As Fig.7, slide the C rail into the sleeve, slide the D rail into the sleeve; slide the E rail into
the sleeve.
2. Cut the plastic thread; pull the screw rod along with inner chain to the end rail position
(Fig.8)
3. As Fig.9, release the nut & spring.
4. Tight the nut to the right position as shown in Fig.10, cut the plastic tape, cut the plastic
thread on sprocket, then whole rail assembled finished.
