5. Locate the vertical adjuster on
the back of each headlamp, then use
a long Phillips #2 screwdriver to
turn the adjuster either
counterclockwise (to adjust down)
or clockwise (to adjust up) aligning
the upper edge of the light pattern
up to the horizontal line.
6. Repeat step 3–5 for the other
headlamp.
7. Close the hood and turn off the lamps.
TURN SIGNAL CONTROL
• Push down to activate the left
turn signal.
• Push up to activate the right turn
signal.
INTERIOR LAMPS
Dome lamps with rear headliner (if equipped)
Dome lamps equipped with an on/off
control will light when:
• doors are closed and the control
is in the
position
• control is in the middle position
and any door is open
• headlamp control is rotated fully
counterclockwise
When the control is in the
D
position, it will not illuminate when you
open the doors or fully rotate the headlamp control.
Lights
54
2010 Econoline (eco)
Owners Guide, 3rd Printing
USA (fus)
