Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
17 20A Cigar Lighter, Data Link
Connector (DLC)
18 — Not Used
19 25A PCM Power Diode, Ignition, PATS
20 7.5A Generic Electronic Module
(GEM), Radio
21 15A Flasher (Hazard)
22 20A Auxiliary Power Socket
23 — Not Used
24 7.5A Clutch Pedal Position (CPP)
switch, Starter Interrupt Relay
25 — Not Used
26 10A Battery Saver Relay, Auxillary
Relay Box, Restraint Central
Module (RCM), Generic Electroic
Module (GEM), Instrument
Cluster
27 — Not Used
28 7.5A Generic Electronic Module
(GEM), Radio
29 20A Radio
30 — Not Used
31 — Not Used
32 — Not Used
33 15A Headlamps, Daytime Running
Lamps (DRL) Module, Instrument
Cluster
34 — Not Used
35 15A or Not Used 15A: Horn Relay if Not Equipped
with Truck Central Security
Module
36 — Not Used
Roadside emergencies
164
