Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
28 20A* Horn relay
29 60A** PJB
30 20A** Rear wiper motor
31 — Not used
32 — Not used
33 30A** Auxiliary blower motor
34 30A** Power seats, Adjustable pedals
35 20A** Rear power point
36 40A** Blower motor
37 15A* A/C clutch relay/Transmission
38 15A* Coil on plug
39 15A* Injectors/Fuel pump relay
40 15A* PTEC power
41 15A* HEGO, VMV, CMS, PTEC
42 10A* Right low beam
43 10A* Left low beam
44 15A* Front foglamps
45 5A* Brake pressure switch
46 20A* High beams
47 — Horn relay
48 — Fuel pump relay
49 — High beam relay
50 — Fog lamp relay
51 — Police IVD relay
52 — A/C clutch relay
53 — Trailer tow right turn
54 — Trailer tow left turn
55 — Blower motor relay
56 — Starter relay
57 — PTEC relay
58 — Ignition relay
Roadside emergencies
235
