GAUGES
Base cluster
Shown in standard measure. Metric similar.
1. Tachometer: Indicates the engine speed in revolutions per minute.
Driving with your tachometer pointer continuously at the top of the scale
may damage the engine.
2. Multifunction display: This displays the engine coolant temperature,
4WD gauge, odometer/trip meter and other vehicle features. This is also
used to configure different vehicle personalization options and display
the status of various vehicle functions. See Standard message center in
this chapter for more information.
32
4
5
4
3
2
1
0
7
F
E
6
km/h
80
60
40
20
0
20
0
40
60
80
100
120
140
160
180
200
220
100
120
140
MPH
1
Instrument Cluster
