Ford 2011 Explorer - Page 332

Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
30 15A Front park lamps
31 5A Trailer tow brake controller
32 15A 110V AC power point, Power folding
mirror, Power mirrors, One touch
up/down front windows, Door lock
illumination
33 10A Occupant classification sensor
34 10A Blind spot monitor, Rearview camera,
Reverse sensing system
35 5A Heads-up display, Climate control
humidity sensor, Terrain management
system, Hill descent switch, Headlamp
switch IGN sense
36 10A Not used (spare)
37 10A Restraints control module
38 10A Auto-dimming rear view mirror, Moon
roof
39 15A High beam headlamps
40 10A Rear park lamps, License plate lamps
41 7.5A Overdrive cancel, Tow/haul
42 5A Not used (spare)
43 10A Not used (spare)
44 10A Not used (spare)
45 5A Not used (spare)
46 10A Climate control module
47 15A Fog lamps, left and right turn signal
mirror feed
48 30A Circuit
Breaker
Rear power windows, Passenger power
window, One touch down (driver side
only)
49 Delayed
accessory relay
Body control module
