Fuse/Relay
Location
Fuse Amp
Rating
Protected circuits
39 20A Radio, Center information display,
Electronic finish panel
40 20A Not used (spare)
41 15A Door lock/sunroof switch
illumination, Auto dimming rear
view mirror, Ambient lighting
42 10A Not used (spare)
43 10A Heated seats relay
44 10A Not used (spare)
45 5A Front wipers (logic)
46 7.5A Front passenger sensing system
47 30A (circuit
breaker)
Sunroof, Power windows
48 — Delayed accessory relay
Power distribution box
The power distribution box is located in the engine compartment. The
power distribution box contains high-current fuses that protect your
vehicle’s main electrical systems from overloads.
WARNING: Always disconnect the battery before servicing high
current fuses.
WARNING: To reduce risk of electrical shock, always replace
the cover to the power distribution box before reconnecting the
battery or refilling fluid reservoirs.
If the battery has been disconnected and reconnected, refer to the
Battery section of the Maintenance and Specifications chapter.
Roadside Emergencies
196
2011 Focus (foc)
Owners Guide, 1st Printing
USA (fus)
