Ford 2013 C-Max Hybrid User Manual

Fuse or relay
number
Fuse amp
rating
Protected components
F16 20A** Body control module 15 feed
F17 20A** Transmission oil pump (C-MAX
Energi)
F18 20A** Front wiper motor
F19 5A* Anti-lock brake system /
Electronic stability program
module
F20 15A* Horn
F21 5A* Stop light switch
F22 5A* Vacuum pump monitoring
F23 5A* Engine control module 15 /
Powertrain control module 15 /
Transmission oil pump 15
F24 5A* Relay coils
F25 10A* Motor electronic cooling pump
F26 5A* Electronic power assist steering
module 15
F27 5A* Mass air flow sensor
F28 15A* Powertrain control module
F29 10A* Electronic A/C compressor /
Positive temperature coefficient
heater
F30 10A* Engine control module,
Powertrain control module
F31 5A* Charge port light ring (C-MAX
Energi)
F32 20A* Vehicle power 2
F33 15A* Vehicle power 4
F34 10A* Injectors
F35 10A* Vehicle power 3
F36 20A* Vehicle power 1
R1 — Not used
268 Fuses
2013 C-Max Full Hybrid (34h)
Owners Guide gf, 2nd Printing
USA (fus)
