Fuse or relay
number
Fuse amp
rating
Protected components
R2 Micro relay Horn
R3 Micro relay Hybrid powertrain control
R4 Micro relay Front wiper
R5 — Not used
R6 Micro relay Front and rear wiper high/low
R7 Power relay Vacuum pump
R8 Power relay Ignition feed
R9 — Not used
R10 Mini relay Vacuum pump sensor
R11 — Not used
R12 Power relay Cooling fan
R13 Mini relay Heater blower
R14 Mini relay Engine control relay
*Mini Fuses **Cartridge Fuses
Fuses 269
2013 C-Max Full Hybrid (34h)
Owners Guide gf, 2nd Printing
USA (fus)
