These are examples of unacceptable moisture (usually caused by a lamp
water leak):
• Water puddle inside the lamp.
• Large water droplets, drip marks or streaks present on the interior of
the lens.
Take your vehicle to a dealer for service if any of the above conditions of
unacceptable moisture are present.
Replacing Headlamp Bulbs
WARNING: Handle a halogen headlamp bulb carefully and keep
out of children’s reach. Grasp the bulb by only its plastic base
and do not touch the glass. The oil from your hand could cause the
bulb to break the next time the headlamps are operated.
Note: If the bulb is accidentally touched, it should be cleaned with
rubbing alcohol before being used.
Locating the Headlamp Bulbs:
A. Turn lamp
B. Low beam headlamp
C. High beam headlamp
Replacing the High Beam
Headlamp Bulb:
1. Remove the headlamp assembly.
2. Remove the service cap.
3. Disconnect the electrical
connector
4. Release the clip and remove the
bulb from the headlamp assembly.
Maintenance 297
2013 C-Max Full Hybrid (34h)
Owners Guide gf, 2nd Printing
USA (fus)
